High Power LED Garden Light Aluminum 1.1W-3.2W DIA 42MM SMD LED Single Color and RGB 3in1 for Landscape Lighting HIGH POWER LED GARDEN LIGHT
Waterproof Rating: IP65
Material: Aluminum anodized finishing or powder painting
Model: 8331X / 8351X Series
Certification: RoHS, CE
High power LED garden light engineered for superior architectural and landscape accentuation.
Features high-strength aluminum housing with options for anodized finishing or professional powder painting.
Equipped with high-performance SMD LEDs and precision optical lenses (efficiency ≥85%) for uniform light distribution.
Offers a wide range of beam angles from narrow 8° to wide 90° for diverse project lighting requirements.
Available in both single color and RGB 3in1 versions to create dynamic and vibrant outdoor lighting effects.
With optional accessories like honeycomb louvers, aluminum bases, and spikes.
Model Specification Table
|
Item No. |
Light source |
Lens beam angle(°) |
Consumption(watt) |
Input Voltage(V) |
Ik rate |
|
83311 / 83511 |
1x1W |
8°/15°/20°/30°/45°/60°/90° |
1.1 |
DC12V/DC24V |
02 |
|
83311H / 83511H |
1x1W |
8°/15°/20°/30°/45°/60°/90° |
1.3 |
AC120V/AC240V |
02 |
|
83312 / 83512 |
1x2W |
8°/15°/20°/30°/45°/60°/90° |
2.2 |
DC12V/DC24V |
02 |
|
83312H / 83512H |
1x2W |
8°/15°/20°/30°/45°/60°/90° |
2.6 |
AC120V/AC240V |
02 |
|
83316 / 83516 |
1x3W RGB3in1 |
30°/45°/60° |
3.2 |
DC12V/DC24V |
02 |
Material Specifications Table
|
Item |
Description |
|
Housing&face cover |
Aluminum anodized finishing or powder painting |
|
Glass |
Tempered glass. T=3mm |
|
Lens |
Optical lens, efficiency≥85% |
|
Cable gland |
Copper and nickel coated |
|
Gasket |
Tooling shaped seal |
|
LED |
SMD LED |
|
PCB |
Excellent heat conductivity aluminum, coefficient of Heat Conductivity≥2.0w/mk |
|
Driver |
Constant current output, single color LED=1-circuit output, RGB 3in1 LED=3-circuit output |
|
Operating temperature |
-20℃~40℃ |
|
Power cable |
H05RN-F 2x0.75mm² L=1m (low voltage) / H05RN-F 3x0.75mm² L=1m (high voltage) / H05RN-F 4×0.75mm² L=1m (for RGB) |
