IP68 LED Stainless Steel Swimming Pool Light 12W CREE LED Single Color RGB RGBW for High-End Aquatic Features Stainless steel LED swimming pool light/Underwater Recessed Light
Waterproof Rating: IP68
Material: Molding shaped 304# or 316L* stainless steel housing & Accessories
Model: 94812X / 9486X Series
Certification: IP68, RoHS, CE
Premium IP68 underwater recessed light designed for luxury swimming pools and architectural water features.
Robust construction using molding shaped 304# or 316L* stainless steel for maximum corrosion resistance in treated water.
High-impact 8mm tempered glass and high-efficiency optical lenses (≥85%) ensure durable and brilliant illumination.
Flexible light distribution with both symmetrical and asymmetrical lens options to highlight pool surfaces and walls.
Wide range of power outputs from 12.1W to 48.1W, featuring CREE LEDs for superior color rendering and longevity.
Reliable submersible performance with IP-68 PG-11 copper and nickel coated cable glands and high-grade silicone seals.
Model Specification Table
|
Item No. |
Light source |
Lens beam angle(°) |
Consumption(watt) |
Input Voltage(V) |
Ik rate |
|
948121(AS) |
12x1W |
8°/15°/25°/30°/45°/60° |
12.6W |
DC24V |
08 |
|
948122(AS) |
12x2W |
8°/15°/25°/30°/45°/60° |
25W |
DC24V |
08 |
|
948123(AS) |
12x1W RGB |
8°/15°/25°/30°/45°/60° |
12.1W |
DC24V |
08 |
|
948124(AS) |
12x2W RGB |
8°/15°/25°/30°/45°/60° |
23.8W |
DC24V |
08 |
|
948126(AS) |
12x3W RGB3in1 |
25°/30°/45°/60° |
35.2W |
DC24V |
08 |
|
948129(AS) |
12x4W RGBW4in1 |
25°/30°/45°/60° |
48.1W |
DC24V |
08 |
|
94869 |
6x5W RGBW4in1 (W=3000K 4000K 6000K) |
15°/25°/30°/45°/60° |
30.6W |
DC24V |
08 |
|
94867 |
6x5W LED |
15°/25°/30°/45°/60° |
35.5W |
DC24V |
08 |
Material Specifications Table
|
Item |
Description |
|
Front cover&Housing |
Molding shaped 304# or 316L* stainless steel |
|
Glass |
Tempered glass T=8mm |
|
Lens |
Optical lens, efficiency≥85% |
|
Cable gland |
IP-68 PG-11 copper and nickel coated |
|
MCPCB |
Excellent heat conductivity aluminum, coefficient of heat conductivity≥2.0w/mk |
|
Driver |
Constant current output. Single color LED=1-circuit output. RGB LED=3-circuits output. RGB 3in1 LED=6-circuits output. |
|
Application environment |
Temperature of water between -20℃ ~ 40℃ less than 1.0 meter depth. |
|
Power cable |
H05RN-F 2*0.75mm² L=2m(for single color) / H05RN-F 4*0.75mm² L=2m(for RGB) / H05RN-F 5*0.5mm² L=2m(for RGBW) |
|
Mounting sleeve |
Plastic |
