Swimming Pool Underwater Light Recessed Type 1W 2W DIA 42mm For Pool Pond Decoration Mini Underwater LED Inground Light/Tiny type swimming pool light
Waterproof Rating: IP68
Material: Molding shaped 304# or 316L* stainless steel
Model: 9001X Series
Certification: IP68, RoHS, CE
Professional mini underwater LED inground light specifically designed for swimming pools, fountains, and wet landscape environments.
Fully constructed with molding shaped 304# or 316L* stainless steel for exceptional corrosion resistance in chlorinated or salt water.
Equipped with high-impact step tempered glass (T=4mm/6mm) and precision optical lenses ensuring ≥85% light efficiency.
Features IP68 waterproof rating and PG9 nickel-coated copper cable glands to ensure complete submersible reliability up to 1.0m depth.
Versatile mounting options with aluminum or plastic sleeves, ideal for recessed installation in pool steps, walls, and floors.
Supports both high-efficiency single color and dynamic RGB 3in1 lighting effects to create vibrant underwater atmospheres.
Model Specification Table
|
Item No. |
Light source |
Lens beam angle(°) |
Consumption(watt) |
Input Voltage(V) |
Ik rate |
|
90011 |
1x1W |
15/25/45/60° |
1.1 |
DC3V 350MA (DC12V/DC24V) |
04 |
|
90012 |
1x2W |
15/25/45/60° |
2.2 |
DC3V 700MA (DC12V/DC24V) |
04 |
|
90011A |
1x1W |
8/15/20/30/45/60° |
1.1 |
DC12V/DC24V |
06 |
|
90012A |
1x2W |
8/15/20/30/45/60° |
2.4 |
DC12V/DC24V |
06 |
|
90016A |
1x3W RGB3in1 LED |
8/15/20/30/45/60° |
3.2 |
DC12V/DC24V |
06 |
|
90011B |
1x1W |
15/25/45/60° |
1.1 |
DC12V/DC24V |
06 |
|
90012B |
1x2W |
15/25/45/60° |
2.4 |
DC12V/DC24V |
06 |
Material Specifications Table
|
Item |
Description |
|
Front cover&Housing |
Molding shaped 304# or 316L* stainless steel |
|
Glass |
Step tempered glass T=4mm / 6mm |
|
Lens |
High quality optical lens, efficiency≥85% |
|
Cable gland |
IP68 PG9 nickel coated copper |
|
PCB |
Excellent heat conductivity aluminum, coefficient of heat conductivity≥2.0w/mk |
|
Driver |
Constant current output. Single color LED=1-circuit output. RGB 3in1 LED=3-circuit output |
|
Application environment |
Temperature of water between -20℃ ~ 40℃ less than 1.0 meter depth |
|
Mounting sleeve |
Aluminum / Plastic sleeve |
|
Power cable |
H05RN-F 2x0.75mm² L=1m(for Single color) / H05RN-F 4x0.75mm² L=1m(for RGB) |
