LED Underground Light
>
|
|
| Place of Origin | Guangdong, China |
| Brand Name | Joyful Partner |
| Model Number | 82691 |
|
Item No.
|
Light source
|
Lens beam angle(°)
|
Consumption(watt)
|
Input Voltage(V)
|
Ik rate
|
|
82691(S/H/AS)
|
9*1W LED
|
8°/15°/25°/30°/45°/60°
|
9.5
|
DC24V/AC100-240V
|
8
|
|
82692(S/H/AS)
|
9*2W LED
|
8°/15°/25°/30°/45°/60°
|
18
|
DC24V/AC100-240V
|
8
|
|
82693(S/AS)
|
9*1W RGB LED
|
8°/15°/25°/30°/45°/60°
|
9.2
|
DC12V/DC24V
|
8
|
|
82694(S/AS)
|
9*3W RGB LED
|
8°/15°/25°/30°/45°/60°
|
24
|
DC12V/DC24V
|
8
|
|
82696(S/H/AS)
|
9*3W RGB3in1 LED
|
25°/30°/45°/60°
|
27
|
DC24V
|
8
|
|
Material specifications
|
|
|
|
Housing
|
Outdoor powder coated aluminum
|
|
|
Front cover
|
304# or 316#Stainless Steel
|
|
|
Lens
|
Optical lens,effciency≥85%
|
|
|
Glass
|
Tempered step glass T=8mm
|
|
|
Gasket
|
Molding shaped silicone seal
|
|
|
Operating temperature
|
(-20℃~40℃)
|
|
|
Power cable
|
H05RN-F2*0.75mm²L=0.5m(low voltage)
H05RN-F3*0.75mm²L=0.5m(for single color/high voltage)
H05RN-F4*0.75mm²L=0.5m(for RGB)
|
|
|
Mounting sleeve
|
ABS
|
|
