IP65 LED Surface Mounting and Up/down Wall Washer Light Extruded Aluminum 18W-24W DIA 97MM CREE COB LED Single Color Surface mounting wall washer light/Up/down wall washer light
Waterproof Rating: IP65
Material: Extruded aluminum alloy
Model: WL100X Series
Certification: IP65, RoHS, CE
Professional-grade architectural wall washer light designed for versatile vertical and facade illumination.
Features both surface mounting and bi-directional up/down lighting versions to suit diverse project needs.
Constructed with high-quality extruded aluminum alloy housing for optimal heat management and durability.
Equipped with high-performance CREE COB LEDs providing powerful output ranging from 18W to 24W.
Precision optical lens with ≥85% efficiency offers 15°, 38°, or 60° beam angle options for focused lighting effects.
Fully IP65 waterproof rated and IK05 impact resistant, engineered for reliable performance in outdoor environments.
Model Specification Table
|
Item No. |
Light source |
Lens beam angle(°) |
Consumption(watt) |
Input Voltage(V) |
Ik rate |
|
WL100188 |
1*18W CREE COB |
15°/38°/60° |
18W |
DC12V/DC24V AC220V/AC240V |
05 |
|
WL100248 |
2*12W CREE COB |
15°/38°/60° |
24W |
DC12V/DC24V AC220V/AC240V |
05 |
Material Specifications Table
|
Item |
Description |
|
Housing |
Extruded aluminum alloy |
|
Glass |
Tempered glass. T=3mm |
|
Lens |
Optical lens, efficiency≥85% |
|
Cable gland |
Copper and nickel coated |
|
Gasket |
Tooling shaped seal |
|
LED |
CREE COB LED |
|
Operating temperature |
-20℃~40℃ |
|
Power cable |
H05RN-F 2x0.75mm² L=0.5m (low voltage) / H05RN-F 3x0.75mm² L=0.5m (high voltage) |
