3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner

3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner

Large Image :  3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner

Product Details:
Place of Origin: Guangdong, China
Brand Name: Joyful partner
Certification: CE,ROHS,IP65,TUV,ISO
Model Number: 819067
Payment & Shipping Terms:
Minimum Order Quantity: 20 pieces
Price: Negotiable
Packaging Details: carton box packing
Delivery Time: 5-10 working days
Payment Terms: T/T, Paypal., Western Union, MoneyGram
Supply Ability: 500000 Piece/Pieces per Week
Contact Now

3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner

Description
Color Temperature(CCT): 2700k-6000k Input Voltage(V): DC12V24V/AC100-240V
Warranty(Year): 2-Year Color Rendering Index(Ra): 80
Usage: Staircase Voltage: 100-240V
Base Material: Aluminum Diffuser: Tempered Glass
Light Source: LED Lighting Solutions Service: Project Installation
Lifespan (hours): 50000 Working Time (hours): 50000
Product Weight（kg）: 0.5 Product Name: Led Step Light
Material: Aluminum Body IP Rating: IP65
Style: Morden Installation Method: Recessed
Keyword: Led Wall Light Stair Light Step Light Corner Light Wattage: 3W 5W
Color: White,grey,support Cutomization Application: Garden, Coner,stair, Path
Highlight:

3W LED Recessed Wall Light

,

5W LED Recessed Wall Light

,

IP65 LED Linear Recessed Lighting

3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner

Item No.
Light source
Lens beam angle(°)
Consumption(watt)
Input Voltage(V)
Ik rate
819067
SMD5630*6
N/A
3
DC12V/DC24V
AC100-240V
9
819058
1*5W COB LED
N/A
5.5
DC12V/DC24V
AC100-240V
9
Material specifications

Housing&Front cover
Made of ADC12#Die-casting outdoor powder coated aluminum
Glass
Tempered glass.T=4mm
Lens
Optical lens,effciency≥85%
Gasket
Tooling shaped seal
LED
SMD or COB LED,Ra>80
PCB
Excellent heat conductivity aluminum,
coeffcient of heat conductivity≥2.0w/mk
Driver
Constant current output
single color LED=1-circuit output
Operating temperature
(-20℃~40℃)
Power cable
H05RN-F2*0.75mm²L=0.3m(low voltage)
H05RN-F3*0.75mm²L=0.3m(high voltage)
1. Brand LED high lumen,energy saving,soft light,
2. Anti-oxidation all-aluminum housing,
3. CE & RoHS proved
4. IP65 Waterproof
5. Support DMX512,Dali,0-10V dimmable etc...
6. Square, Round, linear shape meet various engineering needs
7. Outdoor and Indoor Step/Stair/corridor both can be used.
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 0
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 1

3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 2
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 3
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 4
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 5
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 6
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 7
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 8
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 9
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 10
3W LED Recessed Wall Light SMD5630 ADC12 Die-casting Aluminum 120° Beam Angle For Stair Corner 11

Tag:

Outdoor Walkway Lighting,

Outdoor LED Step Light,

LED Staircase Step Light
