Item No.
|
Light source
|
Lens beam angle(°)
|
Consumption(watt)
|
Input Voltage(V)
|
Ik rate
|
|
82511
82511S
82511AS
|
1*1W LED
|
8°/15°/30°/45°/60°
|
1.2
|
DC12V
DC24V AC100-240V |
8
|
|
82512
82512S
82512AS
|
1*3W LED
|
8°/15°/30°/45°/60°
|
3
|
DC12V
DC24V AC100-240V |
8
|
|
82516
82516S
82516AS
|
1*3W
RGB3in1 LED |
30°/45°/60°
|
3.1
|
DC12V
DC24V |
8
|
|
D82517
D82517S
|
1*0.5W LED
|
120°
|
0.5
|
DC12V
DC24V AC100-240V |
8
|
|
Material specifications
|
|
|
|
Housing
|
Extruded aluminum alloy #6063,anodic oxidation or outdoor powder painting
|
|
|
Front cover
|
304# or 316#Stainless Steel
|
|
|
Lens
|
Optical lens,effciency≥85%
|
|
|
Glass
|
Tempered glass.T=7mm
|
|
|
Gasket
|
Molding shaped silicone double seal
|
|
|
Operating temperature
|
(-20℃~40℃)
|
|
|
power cable
|
H05RN-F2*0.75mm²L=0.5m(low voltage)
H05RN-F3*0.75mm²L=0.5m(for single color/high voltage) H05RN-F4*0.75mm²L=0.5m(for RGB) |
|
|
Mounting sleeve
|
ABS
|
|
|
Optional accessory
|
Honeycomb
|
|
